5 kW 12V Diesel Air Heater K5AL2209-12 with High-Altitude Mode
$195.00
Skip to product information
5 kW 12V Diesel Air Heater K5AL2209-12 with High-Altitude Mode
$195.00
The Karlesk K5AL2209-12 is a 5 kW diesel air heater for 12V vans, campers, RVs, boats and off-grid cabins. High-altitude mode keeps it running cleanly in the mountains, and the brushless blower motor is quiet and built for long service life.
Key features
- Heat output 0.9–5 kW (up to 17,000 BTU/h) with stepless adjustment
- High-altitude mode for mountain trips
- Brushless blower motor: quieter operation and longer service life
- Low fuel consumption: 0.2–0.45 L/h (0.05–0.12 gal/h)
- Aluminum housing, cold starts down to −40 °C (−40 °F)
Specifications
| Model | K5AL2209-12 |
|---|---|
| Voltage | 12V DC |
| Heat output | 0.9–5 kW (3,070–17,000 BTU/h), stepless |
| Fuel | Diesel |
| Fuel consumption | 0.2–0.45 L/h (0.05–0.12 gal/h) |
| Dimensions | 410 × 140 × 190 mm (16.1 × 5.5 × 7.5 in) |
| Heater weight | approx. 5 kg (11 lb) |
| Cold start | down to −40 °C (−40 °F) |
| Blower motor | Brushless |
Good to know
- Install the heater inside the vehicle or in a protected compartment and route the exhaust and combustion air intake outside the living space. Professional installation is recommended.
- Use a CO detector in any sleeping area heated by a fuel-burning heater.
- In freezing temperatures use winter-grade diesel to prevent fuel gelling.
